Disc Plough

Disc Plough

Catalog

Disc Plough

General Features :

In conformity with the current agricultural conditions are available in 2,  3, 4, 5 and 6 disc version.

Disc ploughs have an excellent performance in every type of soil by the basic principles such as soil breaking, soil raising, soil turning and soil mixing. The disc ploughs are used to open the new fields and to process the stony areas.

While processing, it avoids the occurrence of the big holes and the upper part of furrow’s becoming muddy. There is no possibility to be stopped up with grass, helves and farm fertilizer. Its special design allows to easier work in rocky and rooted areas. Upon this feature, the damage that may occur in disc ploughs and tractor can be prevented.

The use life of plough chassis and discs are rather long particulary the discs are boron steel from Turkey, Bellota from Spain or Forge de Niaux from France, 52-55 Rhe hardness, Ø660 mm and are adjustable to get the maximum performance from the power of tractor.



Technical





Units

MODELS

ARDP2

ARDP3

ARDP4

ARDP5

ARDP6

Number of Discs

pcs

2

3

4

5

6

Total Length

 cm

156

213

252

290

333

Total Width

 cm

111

126

142

157

172

Total Height

cm

123

123

123

123

123

Working Depth

cm

25

25

25

25

25

Working Width

cm

66

99

132

165

198

Space of Disc

cm

53

53

53

53

53

Diameter of Disc

mm

660

660

660

660

660

Tractor Power

hp

35-40

55-60

70-80

85-90

100-110

Total Weight

kg

310

400

470

540

610
