Mounted Fertilizer Spreader Amazon

Fertilizer spreaders mounted to the Tractors through three point linkage system. It is powered by throughout a rod by tractor PTO and linked up by spreader discs and smashers in the tank. With the action of the output rods the discs turns and the fertilizer are spreading by the discs. Spreading degree can be easily adjusted by means of the mechanical lever and hydraulic lift.

Tecnical Features Units Models
AFS-N 1000 AFS-N 1200 AFS-N 1500
Number of Discs pcs 2 2 2
Hopper Capacity lt. 1000 1280 1550
Total Width cm 213 238 238
Working Width m 24-36 24-36 24-36
Total Length cm 140 151 151
Total Height cm 130 142 160
P.T.O. rpm 540 540 540
Weight kg 360 395 408
Stainless Steel Disc & Wings   Standard Standard Standard
2-way  Auto Control   Standard Standard Standard
Fertilizer Adjust Sys.   Hydraulic Hydraulic Hydraulic
